Your benefits at a glance

An extra-low patient positioning (patient surface height 28 cm) reduces the risk of injuries in case of a fall out of the bed, especially during the night.

The special design of the SafeFree®-side rails provides support and helps the patients mobilize themselves. Different height settings allow the adaption of side rails to the individual patient's needs for protection and the design without middle posts or central gap protector allow unrestricted access to the patient..

The special design of the SafeFree®-side rails provides support and helps the patients mobilize themselves. An optimal adjustment to the individual mobilization height for different patient sizes is possible thanks to the flexible height settings.

27 cm = Sleep
41 cm = Mobilization
80 cm = Nursing care

In addition, the new member of the image 3 series convinces through a homely hotel design, which provides the ambiance of a healing environment through its universal usability, not just in rooms with additional services.

It not only significantly simplifies bed transport by only one person in narrow hospital rooms, but also masters the difficult transport to the main bed storage area or to operating rooms without a problem.

image 3-w thus not only corresponds with AK-BWA requirements, but the versatile clinic bed also took part in an extensive test series in the Miele Professional large-chamber washer and proved its suitability.

Technical features

External dimensions

221 cm x 104 cm
Mattress platform dimensions 200 cm x 86/90 cm
Bed extension 10; 22; 30.5 cm
Maximum mattress height with SafeFree®-split siderails 18 cm
Maximum mattress height with single collapsible siderails 17 cm
Mattress platform height adjustment 28 – 80 cm
Maximum backrest angle 70°
Maximum thigh rest angle 34°
Trendelenburg/Anti-Trendelenburg position 14°/14°
Ergoframe 10 cm / 6 cm
Safe working load 265 kg (Standard) | 265 kg (Washable) | 320 kg (XXL)
Bed weight 160 kg* **

* - by configuration
** - by accessories

  • Height adjustment – motor
  • TR/ATR tilt adjustment – motor
  • Backrest adjustment – motor
  • Thigh rest adjustment – motor
  • Calf rest  - manual
  • Bed extension – manual
  •

  • Handset
  • Supervisor panel
  •

  • Split, telescopic SafeFree®- side rail concept protecting the full length if required
  • Single collapsible side rail with a top locking mechanism
  •

    Ergoframe with double retraction:

    +16cm


    Special scissor construction provides reduced height of just 28 cm above floor level when 125 mm castors are used.
  • Central locking of all castors from 2 points
  • Central locking of all castors from 4 points (O)
  • 4 double castors ⌀125 mm Tente Linea
  • 4 double castors ⌀150 mm Tente Linea (O)
  • 4 castors ⌀150 mm Tente Integral (O)
  • Antistatic Castor
  • Back

    Quality marks & Awards

    IFAward 2016 Winner MK award
